Safe Swift code can’t corrupt memory. But the moment you use Unsafe pointers, call into C or C++, or depend on a library that does, memory bugs are possible again, and they’re the worst kind: crashes far from the cause, wrong values that appear only sometimes, or no visible symptom at all until a user’s data is corrupted. Address Sanitizer (ASan) catches these bugs at the exact line where they happen, with a report that tells you where the memory was allocated and freed.

Finding Memory Bugs with Address Sanitizer

What Address Sanitizer finds

Bug	What happens
Heap use after free	reading or writing memory that was already deallocated
Heap buffer overflow	accessing past the end (or before the start) of an allocation
Stack buffer overflow	the same, for memory on the stack
Stack use after return / scope	using a pointer to a local variable after its function or scope ended
Double free	deallocating the same memory twice
Invalid free	deallocating memory that wasn’t allocated that way

It works for Swift, C, C++, and Objective-C code in the same process, which matters, because the bug is often at a language boundary.

Enabling it

In Xcode: Product → Scheme → Edit Scheme → Run → Diagnostics → Address Sanitizer. Enable it for the Test action too, to run your whole test suite with memory checking.

From the command line, with Swift Package Manager:

swift build --sanitize=address
swift test --sanitize=address

ASan rebuilds your code with a check before every memory access. Expect it to run roughly two to three times slower and to use noticeably more memory. That’s fine for debugging and testing, and it’s why you don’t ship it.

How it works

ASan has three main tricks:

1. Shadow memory. For every 8 bytes of your app’s memory, ASan keeps 1 byte of “shadow” memory that records how many of those bytes are valid to access. The compiler inserts a check before every load and store: look up the shadow byte, and if the access touches invalid bytes, stop and report.
2. Red zones. Every allocation gets poisoned padding before and after it. Stepping even one byte outside a buffer lands in a red zone, which the shadow memory marks as invalid.
3. Quarantine. Freed memory isn’t handed out again immediately. ASan poisons it and holds it in a quarantine queue for a while, so a later access to it is caught as a use-after-free, instead of silently reading whatever was allocated there next.

The result: bugs that would normally corrupt memory silently are reported at the very first bad access.

Use after free

func makeDanglingPointer() -> UnsafeMutablePointer<Int> {
    let pointer = UnsafeMutablePointer<Int>.allocate(capacity: 1)
    pointer.initialize(to: 42)
    pointer.deinitialize(count: 1)
    pointer.deallocate()
    return pointer                // the memory is already freed
}

let dangling = makeDanglingPointer()
// print(dangling.pointee)       // heap-use-after-free: ASan stops right here

Without ASan, that print might show 42, a random number, or crash much later. With ASan, Xcode stops on the faulty line with heap-use-after-free.

Heap buffer overflow

func sumFirstFour(_ values: [Int]) -> Int {
    values.withUnsafeBufferPointer { buffer in
        var total = 0
        for index in 0..<4 {
            total += buffer.baseAddress![index]    // raw pointer access: no bounds check
        }
        return total
    }
}

// sumFirstFour([1, 2, 3])        // heap-buffer-overflow: reads one element past the end

Swift arrays check their bounds, and so do UnsafeBufferPointer subscripts in debug builds. But baseAddress! turns the buffer into a raw UnsafePointer, which checks nothing. ASan reports heap-buffer-overflow at the faulty read. Iterating buffer directly, or indexing it instead of baseAddress, avoids the bug.

Stack buffer overflow

func readPastLocal() -> Int {
    var value = 0
    return withUnsafeMutablePointer(to: &value) { pointer in
        pointer.advanced(by: 1).pointee     // reads the 8 bytes after `value`
    }
}

// print(readPastLocal())          // stack-buffer-overflow

Escaping a pointer to a local variable

func escapedPointer() -> UnsafeMutablePointer<Int> {
    var local = 42
    return withUnsafeMutablePointer(to: &local) { $0 }   // the pointer outlives `local`
}

// print(escapedPointer().pointee)   // undefined behavior

This is the most common pointer mistake in Swift: the pointer from withUnsafe… is only valid inside the closure. Interestingly, ASan doesn’t catch this one with its default settings: it just prints a garbage number. Turn on the stricter check by adding an environment variable to your scheme (Edit Scheme → Run → Arguments → Environment Variables):

ASAN_OPTIONS=detect_stack_use_after_return=1

With it, ASan moves local variables to a special heap-backed area and reports stack-use-after-return at the bad read. It’s off by default because it costs extra memory, but it’s worth enabling when you suspect stack pointer bugs.

Double free

let buffer = UnsafeMutablePointer<UInt8>.allocate(capacity: 16)
buffer.deallocate()
// buffer.deallocate()              // attempting double-free

Reading a report

An ASan report has a consistent structure:

1. The bug type and address, like heap-use-after-free on address 0x6020000000f0.
2. The faulty access: a read or write of N bytes, with the stack trace where it happened.
3. Where the memory was freed, for use-after-free and double free, with a stack trace.
4. Where it was originally allocated, with a stack trace.
5. A shadow memory map around the address, rarely needed.

The first trace tells you where the program misbehaved. The other two tell you why the memory wasn’t valid anymore. Together, they usually point straight at the bug: “this object was freed here, but this other code still kept a pointer to it.” Xcode shows the same information in the Issue navigator, and lets you jump to each frame.

Limitations

• It only finds bugs on code paths you run. Good test coverage is what makes ASan effective.
• It doesn’t detect uninitialized reads or data races. Use Thread Sanitizer for races; it can’t be enabled together with ASan, so run them in separate passes.
• It slows things down and changes memory layout and timing, so it’s for debug builds, tests, and CI, not for production.
• Code must be rebuilt with instrumentation. Precompiled binaries you link against aren’t checked internally, although their calls to malloc and free are still tracked.

Related tools

Tool	Finds
Address Sanitizer	use-after-free, buffer overflows, double frees, stack misuse
Thread Sanitizer	data races between threads
Undefined Behavior Sanitizer	undefined behavior in C-family code, like misaligned pointers or signed overflow
Malloc Scribble	fills freed memory with 0x55, so stale reads return obviously wrong values
Guard Malloc	puts each allocation on its own page so overflows crash immediately (simulator and macOS)
Zombie Objects	messages sent to deallocated Objective-C objects

When to reach for it

• Your app uses unsafe pointers, C or C++ code, or native third-party libraries.
• You see crashes that make no sense: EXC_BAD_ACCESS in unrelated code, corrupted values, crashes that disappear when you add logging.
• Regularly, in CI: run the test suite with ASan enabled on a schedule, so memory bugs are caught soon after they’re introduced.

In pure, safe Swift, ASan has very little to find. That’s a good argument for keeping unsafe code small and wrapped in safe types, so the area ASan has to cover stays small too.

Interview questions

How does Address Sanitizer detect an out-of-bounds access? Allocations are surrounded by poisoned red zones tracked in shadow memory; the compiler adds a check before every access, and touching a poisoned byte triggers a report.

Why does ASan catch use-after-free reliably? Freed memory is poisoned and quarantined instead of being reused immediately, so later accesses hit poisoned shadow bytes.

Can you run Address Sanitizer and Thread Sanitizer together? No. Each needs its own instrumentation and memory layout; run them in separate test passes.

Why ship without ASan? It roughly doubles or triples CPU time and increases memory use; it’s a debugging tool, not a runtime safety net.

Summary

• ASan detects use-after-free, buffer overflows, stack misuse, and double frees at the exact faulty access.
• It works by shadow memory, poisoned red zones, and a quarantine for freed memory.
• Enable it in the scheme’s Diagnostics tab or with --sanitize=address; add detect_stack_use_after_return=1 for escaped stack pointers.
• Reports show the bad access, where memory was freed, and where it was allocated.
• Use it whenever unsafe pointers or C/C++ code are involved, and run your tests with it in CI.
